Main features:
This filling machine is suitable for filling of one ton barrels or four 200kg barrels with small opening. The position of the filling head is controlled manually. The top filling type or bottom filling type can be chosen. Barrels are transported by forklift.
Main application:
Coating, paint, ink, glue, curing agent, solvent, chemicals, detergent, pesticide, medicine, lubrication oil and all kinds of flowing liquid.
Main functions:
- Suitable for one tone barrels or four 200kg barrels with small opening
- Barrels are transported by forklift
- The position of filling head is controlled manually
- Installed with ventilation interface to meet the requirement of environmental protection
- Anti-splash filling head
- II is top filling type, III is bottom filling type
- 10 groups of prescription can be set and stored in machine
- Filling fast/slow two steps of filling speed
- Emergent stop/break/barrel moves, twice protection
- Balance exceeding automatic alarm
- Barrel with automatic material supply control
- Explosion proof grade: EXDIIBT6
Main technical parameters:
| Item | Value | Item | Value |
|---|---|---|---|
| Filling scope | ≤1500kg | Power source | AC380V±10% 50HZ |
| Division value | 100kg | Air source | 0.5Mpa |
| Filling accuracy | ≤±0.2kg | The length | 1.5m×3 |
| Filling speed | (200kg) | Power | 0.55kw×3 |
| Barrel size | ≤Ø600×H930 | Filling locations | 1/4 |
