Main function:
- Capable of continuously filling four open-drums; the filling scope of a single barrel is 200kg, max weight scope is 2000kg
- Input and output of barrels are all controlled by PLC. Micro-switch for orientation, continuous filling
- Filling head autorotation, enters the barrel mouth automatically
- Anti-splash filling head
- 30 groups of data setting can be stored
- Automatic peel off, weighing value shows directly
- Two filling speed — fast filling/slow filling
- Emergency stop/power off twice protection
- Automatic alarm when filling weight exceeds
- Feed pump automatically controlled by the machine
- Manual/Automatic operation mode
- Explosion proof grade: EXD Ⅱ BT6
Suitable area:
Dope, oil paint, printing ink, pastern, organic solvent, daily chemical, detergent, pesticide, medicine, lubricant, food oil and all kinds of flowing liquid.
Main technical parameters:
| Item | Value | Item | Value |
|---|---|---|---|
| Filling scope | ≤2000kg | Barrel size | ≤Ø600×H930 |
| Division value | 0.2kg | Power source | AC380V±10% 50HZ |
| Filling accuracy | ≤±0.4kg | Air source | 0.5Mpa |
| Filling speed | 40–60barrels/hour | Size of scale (length×width) | 1500×1500(mm) |
| Filling locations | 4 | Roller conveyer length | 4.5m, 7.5m |
